The Carlyle

House Plan #511
#1 Select Plan Type
#2 Select Reverse Option
#3 Select Exterior Wall & Foundation Type

Plan Type: PDF, Review, CAD explained below. Learn more here.

Plan selections of Reverse, Exterior Wall and Foundation Type may delay delivery by 3 to 5 weeks. Contact us for estimated date.
$1,575.00 USD
$1,575.00 USD
Sale Sold out
house plan modifications

Additional Specs:

  • Total Living: 2082 sq. ft.
  • Bedrooms: 3
  • Full Baths: 2
  • Stories: 1
  • House Dimensions: 47' 10" x 86' 4"
  • **Foundation: Crawl Space
  • Exterior Wall Construction: 2x4
  • Garage Bays: 2
  • Garage Load: Courtyard
**Alternate foundations may be available for an additional charge.

Unfinished Square Footage:

  • Bonus Room: 466 sq. ft.
  • Garage/Storage: 606 sq. ft.
  • Porch: 482 sq. ft.

Plan Types Explained:

AutoCAD file with Unlimited Build

Electronic files emailed of the complete set of construction drawings, only to be used with AutoCAD compatible software. Comes with UNLIMITED license to build home. Please consult a professional before purchasing. (Free PDF file included. NON REFUNDABLE)

PDF Reproducible Set

One full set construction drawings in PDF format is emailed and provides license for unlimited copies to be printed to build the home ONE time. (Emailed within 1 business day. NON REFUNDABLE)

PDF Review Set

One PDF set of construction drawings stamped "Not For Construction" - for review only. May be upgraded to a PDF or AutoCAD within 180 days with payment of a nominal upgrade fee plus difference in cost. NO license to build is provided.

Open, Flowing Design

Attention to detail is what makes this plan special. We included wrapping porches, special ceiling treatments, bay windows, interior columns, built-in bookshelves, and plenty of storage space in this three-bedroom traditional home. With its open, flowing design, The Carlyle entertains as well as it lives. The dining room receives distinction from its tray ceiling, octagonal shape, and columns, while the great room features a fireplace, built-in bookshelves, and French doors that open onto the front porch. The master suite delights with his and her walk-in closets, back porch access, and a bath with all the amenities. Two additional bedrooms share another full bath, while the upstairs bonus space offers numerous options for expansion.
