The Sedona Ridge

House Plan #986
#1 Select Plan Type
#2 Select Reverse Option
#3 Select Exterior Wall & Foundation Type

Plan Type: PDF, Review, CAD explained below. Learn more here.

Plan selections of Reverse, Exterior Wall and Foundation Type may delay delivery by 3 to 5 weeks. Contact us for estimated date.
$1,675.00 USD
$1,675.00 USD
Sale Sold out
house plan modifications

Additional Specs:

  • Total Living: 2843 sq. ft.
  • Bedrooms: 3
  • Full Baths: 2
  • Half Baths: 1
  • Stories: 1
  • House Dimensions: 89' 2" x 92' 1"
  • **Foundation: Crawl Space
  • Exterior Wall Construction: 2x4
  • Garage Bays: 2
  • Garage Load: Courtyard
**Alternate foundations may be available for an additional charge.

Unfinished Square Footage:

  • Garage/Storage: 550 sq. ft.
  • Porch: 752 sq. ft.

Plan Types Explained:

AutoCAD file with Unlimited Build

Electronic files emailed of the complete set of construction drawings, only to be used with AutoCAD compatible software. Comes with UNLIMITED license to build home. Please consult a professional before purchasing. (Free PDF file included. NON REFUNDABLE)

PDF Reproducible Set

One full set construction drawings in PDF format is emailed and provides license for unlimited copies to be printed to build the home ONE time. (Emailed within 1 business day. NON REFUNDABLE)

PDF Review Set

One PDF set of construction drawings stamped "Not For Construction" - for review only. May be upgraded to a PDF or AutoCAD within 180 days with payment of a nominal upgrade fee plus difference in cost. NO license to build is provided.

Southwestern Style

This Southwestern enchanter showcases a stucco exterior with parapet walls and a tile roof. Stone creates the gated courtyard wall, and a beautiful fountain and entryway foreshadow what is to come. French doors and windows usher in light and views, while columns and a fireplace complement the great room. A bay window extends the dining room, and the rear loggia's fireplace is perfect to set the mood for alfresco dining and entertaining. The spacious kitchen features an angled stovetop island. The exquisite master suite includes an intimate sitting nook, a fireplace, large walk-in closet, dressing area, well-appointed bath and private garden. Note the powder room and hall niche.
