The Flannery

House Plan #514
#1 Select Plan Type
#2 Select Reverse Option
#3 Select Exterior Wall & Foundation Type

Plan Type: PDF, Review, CAD explained below. Learn more here.

Plan selections of Reverse, Exterior Wall and Foundation Type may delay delivery by 3 to 5 weeks. Contact us for estimated date.
$1,475.00 USD
$1,475.00 USD
Sale Sold out
house plan modifications

Additional Specs:

  • Total Living: 1609 sq. ft.
  • Bedrooms: 3
  • Full Baths: 2
  • Stories: 1
  • House Dimensions: 66' 4" x 51' 6"
  • **Foundation: Crawl Space
  • Exterior Wall Construction: 2x4
  • Garage Bays: 2
  • Garage Load: Side
**Alternate foundations may be available for an additional charge.

Unfinished Square Footage:

  • Garage/Storage: 500 sq. ft.
  • Porch: 423 sq. ft.
  • Porch - Screened: 181 sq. ft.

Plan Types Explained:

AutoCAD file with Unlimited Build

Electronic files emailed of the complete set of construction drawings, only to be used with AutoCAD compatible software. Comes with UNLIMITED license to build home. Please consult a professional before purchasing. (Free PDF file included. NON REFUNDABLE)

PDF Reproducible Set

One full set construction drawings in PDF format is emailed and provides license for unlimited copies to be printed to build the home ONE time. (Emailed within 1 business day. NON REFUNDABLE)

PDF Review Set

One PDF set of construction drawings stamped "Not For Construction" - for review only. May be upgraded to a PDF or AutoCAD within 180 days with payment of a nominal upgrade fee plus difference in cost. NO license to build is provided.

Modest Ranch House Plan

Outdoor living options abound with this home's front porch, screened-in back porch, and rear deck, making this a great home for entertaining as well as relaxing. Living areas are open and casual, including the great room which boasts a fireplace and a cathedral ceiling that continues out to the popular screened porch. Open to a sunny breakfast bay, the kitchen is also adjacent to the formal dining room with elegant tray ceiling and columns. The split bedroom design promises privacy for the master suite which features a tray ceiling and an indulgent bath with walk-in closet. Two additional bedrooms share a full bath on the opposite side of the home.
