• Front view illustration. The Springdale plan 419.
  • Rear view illustration. The Springdale plan 419.
1 2
Photographs may reflect modified homes.
2832*
Square Feet
4
Bedrooms
2.5
Baths
2
Stories

* Square Footage does not include "Bonus Room" or other unfinished/optional spaces shown on the floor plan.

This is the first floor plan image for two story house plan 419 The Springdale
This is the second floor plan image for four bedroom house plan 419 The Springdale
This is the first floor plan image for southern living house plan 419 The Springdale if the home is built over a basement

The Springdale

House Plan #419
#1 Select Plan Type
#2 Select Reverse Option
#3 Select Exterior Wall & Foundation Type

Plan Type: PDF, Review, CAD explained below. Learn more here.

Plan selections of Reverse, Exterior Wall and Foundation Type may delay delivery by 3 to 5 weeks. Contact us for estimated date.
$1,675.00 USD
$1,675.00 USD
Sale Sold out
house plan modifications

Additional Specs:

  • Total Living: 2832 sq. ft.
  • Bedrooms: 4
  • Full Baths: 2
  • Half Baths: 1
  • Stories: 2
  • House Dimensions: 66' 10" x 47' 8"
  • **Foundation: Crawl Space
  • Exterior Wall Construction: 2x4
  • Garage Bays: 2
  • Garage Load: Side
**Alternate foundations may be available for an additional charge.

Unfinished Square Footage:

  • Bonus Room: 486 sq. ft.
  • Garage/Storage: 738 sq. ft.
  • Porch: 466 sq. ft.

Plan Types Explained:

AutoCAD file with Unlimited Build

Electronic files emailed of the complete set of construction drawings, only to be used with AutoCAD compatible software. Comes with UNLIMITED license to build home. Please consult a professional before purchasing. (Free PDF file included. NON REFUNDABLE)

PDF Reproducible Set

One full set construction drawings in PDF format is emailed and provides license for unlimited copies to be printed to build the home ONE time. (Emailed within 1 business day. NON REFUNDABLE)

PDF Review Set

One PDF set of construction drawings stamped "Not For Construction" - for review only. May be upgraded to a PDF or AutoCAD within 180 days with payment of a nominal upgrade fee plus difference in cost. NO license to build is provided.

A two-story design with Southern Living charm

Columns between the foyer and living room/study hint at all the extras in this four-bedroom country estate with warm, welcoming exterior. Transom windows over French doors open up the living room/study to the front porch, while a generous family room accesses the covered back porch. Nine-foot ceilings amplify the first floor. All bedrooms are upstairs, including a deluxe master suite with a tray ceiling and a bath with a sunny garden tub bay and ample closet space. Access the bonus room from the second floor.
