The Arnold

House Plan #1638
#1 Select Plan Type
#2 Select Reverse Option
#3 Select Exterior Wall & Foundation Type

Plan Type: PDF, Review, CAD explained below. Learn more here.

Plan selections of Reverse, Exterior Wall and Foundation Type may delay delivery by 3 to 5 weeks. Contact us for estimated date.
$1,675.00 USD
$1,675.00 USD
Sale Sold out
Design in Progress Working drawings not yet available.
Contact us for more information.
house plan modifications

Additional Specs:

  • Total Living: 2384 sq. ft.
  • Bedrooms: 4
  • Full Baths: 3
  • Stories: 1.5
  • House Dimensions: 51' 8" x 76' 2"
  • **Foundation: Crawl Space
  • Exterior Wall Construction: 2x4
  • Garage Bays: 2
  • Garage Load: Side
**Alternate foundations may be available for an additional charge.

Unfinished Square Footage:

  • Bonus Room: 558 sq. ft.

Plan Types Explained:

AutoCAD file with Unlimited Build

Electronic files emailed of the complete set of construction drawings, only to be used with AutoCAD compatible software. Comes with UNLIMITED license to build home. Please consult a professional before purchasing. (Free PDF file included. NON REFUNDABLE)

PDF Reproducible Set

One full set construction drawings in PDF format is emailed and provides license for unlimited copies to be printed to build the home ONE time. (Emailed within 1 business day. NON REFUNDABLE)

1 Review Set

One PDF set of construction drawings stamped "Not For Construction" - for review only. May be upgraded to a PDF or AutoCAD within 180 days with payment of a nominal upgrade fee plus difference in cost. NO license to build is provided.

Small Barndominium House Plan

This two-story barndominium features a board-and-batten facade complemented by decorative gable trusses and a stone chimney. The two-story great room flows into an open dining area and an island kitchen. Skylights and a sun tunnel bring natural light into the master suite. Across the floor plan, two additional bedrooms share a full bathroom. The two-car garage is located at the rear of the home and leads into a mudroom with an adjoining pantry and utility room. Upstairs, find a bedroom, full bathroom, and an optional bonus room.
