The Raymond

House Plan #1633
#1 Select Plan Type
#2 Select Reverse Option
#3 Select Exterior Wall & Foundation Type

Plan Type: PDF, Review, CAD explained below. Learn more here.

Plan selections of Reverse, Exterior Wall and Foundation Type may delay delivery by 3 to 5 weeks. Contact us for estimated date.
$2,375.00 USD
$2,375.00 USD
Sale Sold out
house plan modifications

Additional Specs:

  • Total Living: 3261 sq. ft.
  • Bedrooms: 5
  • Full Baths: 3
  • Half Baths: 1
  • Stories: 2
  • House Dimensions: 71' 0" x 68' 9"
  • **Foundation: Hillside Walkout
  • Exterior Wall Construction: 2x4
  • Garage Bays: 2
  • Garage Load: Side
**Alternate foundations may be available for an additional charge.

Unfinished Square Footage:

  • Bonus Room: 563 sq. ft.
  • Other Storage: 1180 sq. ft.
  • Garage/Storage: 653 sq. ft.
  • Porch: 427 sq. ft.
  • Porch - Front: 291 sq. ft.
  • Porch - Screened: 325 sq. ft.

Plan Types Explained:

AutoCAD file with Unlimited Build

Electronic files emailed of the complete set of construction drawings, only to be used with AutoCAD compatible software. Comes with UNLIMITED license to build home. Please consult a professional before purchasing. (Free PDF file included. NON REFUNDABLE)

PDF Reproducible Set

One full set construction drawings in PDF format is emailed and provides license for unlimited copies to be printed to build the home ONE time. (Emailed within 1 business day. NON REFUNDABLE)

PDF Review Set

One PDF set of construction drawings stamped "Not For Construction" - for review only. May be upgraded to a PDF or AutoCAD within 180 days with payment of a nominal upgrade fee plus difference in cost. NO license to build is provided.

Hillside Walkout Modern Farmhouse

This family-friendly design features a modern farmhouse facade and a walkout basement foundation. The floor plan offers an easy flow from the island kitchen to the open great room and dining area. Outdoor living is abundant with front and rear porches. The master suite is spectacular with a vaulted ceiling, outdoor access, and a walk-in closet connection to the utility room. Across the floor plan, two bedrooms share a full bathroom. An optional bonus room is upstairs while two bedrooms and a recreation room are on the basement level.
