• This is an illustration of the front of narrow lot house plan 1172 The Arcadia
1 1
Photographs may reflect modified homes.
3050*
Square Feet
4
Bedrooms
4.5
Baths
1.5
Stories

* Square Footage does not include "Bonus Room" or other unfinished/optional spaces shown on the floor plan.

This is the first floor plan image for narrow lot house plan 1172 The Arcadia
This is the second floor plan image for cottage house plan 1172 The Arcadia
This is the first floor plan image for two story house plan 1172 The Arcadia if the home is built over a basement

The Arcadia

House Plan #1172
#1 Select Plan Type
#2 Select Reverse Option
#3 Select Exterior Wall & Foundation Type

Plan Type: PDF, Review, CAD explained below. Learn more here.

Plan selections of Reverse, Exterior Wall and Foundation Type may delay delivery by 3 to 5 weeks. Contact us for estimated date.
$1,875.00 USD
$1,875.00 USD
Sale Sold out
house plan modifications

Additional Specs:

  • Total Living: 3050 sq. ft.
  • Bedrooms: 4
  • Full Baths: 4
  • Half Baths: 1
  • Stories: 1.5
  • House Dimensions: 47' 0" x 63' 0"
  • **Foundation: Crawl Space
  • Exterior Wall Construction: 2x4
  • Garage Bays: 2
  • Garage Load: Front
**Alternate foundations may be available for an additional charge.

Unfinished Square Footage:

  • Bonus Room: 311 sq. ft.
  • Garage/Storage: 608 sq. ft.
  • Porch: 345 sq. ft.

Plan Types Explained:

AutoCAD file with Unlimited Build

Electronic files emailed of the complete set of construction drawings, only to be used with AutoCAD compatible software. Comes with UNLIMITED license to build home. Please consult a professional before purchasing. (Free PDF file included. NON REFUNDABLE)

PDF Reproducible Set

One full set construction drawings in PDF format is emailed and provides license for unlimited copies to be printed to build the home ONE time. (Emailed within 1 business day. NON REFUNDABLE)

PDF Review Set

One PDF set of construction drawings stamped "Not For Construction" - for review only. May be upgraded to a PDF or AutoCAD within 180 days with payment of a nominal upgrade fee plus difference in cost. NO license to build is provided.

Two-story European cottage

This house plan's exciting exterior truly radiates curb appeal from the minute you see it. Copper roofing, multiple gable peaks, columns and a stunning mix of siding and stone give off European flair. The interior of the home plan boasts spacious common rooms in addition to large bedrooms. A formal staircase immediately welcomes guests into the foyer, while a living room/study is the ideal home office or gathering spot for guests. Open to the great room, the dining room features one column to distinguish the perimeter and grants an open feel to the home. The great room, with cathedral ceiling and fireplace, breakfast room and kitchen are all open to one another and overlook the rear porch. The master bedroom is located on the first floor for privacy, with a cathedral ceiling, two large walk-in closets and a luxurious master bath. Upstairs, the secondary bedrooms are all spacious and roomy and each has its own bathroom, a rare treat!

View full details
