The Sugarhill
Photographs may reflect modified homes.
1854*
Square Feet
3
Bedrooms
2
Baths
1
Stories

* Square Footage does not include "Bonus Room" or other unfinished/optional spaces shown on the floor plan.

This is the first floor plan image for narrow lot house plan 1050 The Sugarhill
This is the bonus room floor plan image for one story house plan 1050 The Sugarhill
This is the first floor plan image for craftsman house plan 1050 The Sugarhill if the home is built over a basement
The Sugarhill
Rotating Image

The Sugarhill

Plan Number: 1050
#1 Select Plan Type
#2 Select Reverse Option
#3 Select Exterior Wall & Foundation
$1,525.00 USD

Plan Type: PDF, Review, CAD explained below. Learn more.

Plan selections of Reverse, Exterior Wall and Foundation Type may delay delivery by 3 to 5 weeks. Contact us for estimated date.

Additional Specs:

  • *Total Living: 1854 sq. ft.
  • Bedrooms: 3
  • Bathrooms: 2
  • Stories: 1
  • House Dimensions: 45' 8" x 63' 4"
  • **Foundation: Crawl Space
  • Exterior Wall Construction: 2x4
  • Garage Bays: 2
  • Garage Load: Front
  • Bonus Room: 343 sq. ft.
  • Garage/Storage: 499 sq. ft.
  • Porch: 64 sq. ft.
  • Porch - Screened: 130 sq. ft.
* Some plans may increase in square footage to accommodate 2x6 framing.

** Alternate foundations may be available for an additional charge.

Plan Types Explained:

AutoCAD file with Unlimited Build

Electronic files emailed of the complete set of construction drawings, only to be used with AutoCAD compatible software. Comes with UNLIMITED license to build home. Please consult a professional before purchasing. (Free PDF file included. NON REFUNDABLE)
PDF Reproducible Set

One full set construction drawings in PDF format is emailed and provides license for unlimited copies to be printed to build the home ONE time. (Emailed within 1 business day. NON REFUNDABLE)
NFC Review Set

One PDF set of construction drawings stamped "Not For Construction" - for review only. May be upgraded to a PDF or AutoCAD within 180 days with payment of a nominal upgrade fee plus difference in cost. NO license to build is provided.

Historical Charm

Board-n-batten siding and stone create an exciting Craftsman exterior. Combining the historical charm of a row house, a shotgun house and a mill house, this bungalow features a modern floorplan for today's active family. The front-entry garage helps conserve space on a smaller lot. An unobstructed view extends from the front door through French doors to the deck. A tray ceiling and columns enhance the dining room, while an angled counter provides plenty of workspace in the kitchen. French doors lead from the great room and dining room into the screened porch. The bonus room provides space for expansion, and the bedroom/study offers flexibility. Note the laundry sink in the spacious utility/mudroom.
Return Policy

ALL SALES ARE FINAL. Please double-check your selection before ordering. We encourage you to learn the building codes for your area. If you have a builder in mind, show them the plan and determine what they will need to build the home and meet local building codes. Feel free to contact us to discuss any concerns you may have before ordering.
Delivery & Returns

If your order has not arrived as scheduled, please contact our Customer Sales & Support department at 800.388.7580 or email us. PDF and AutoCAD plan packages ordered before noon Eastern Standard Time, Monday-Friday, will be emailed the same day. Orders placed after noon Eastern Standard Time will be emailed the next business day. If you have requested an alternate foundation or wall construction, full reverse option or other modifications to your plan, consult a Customer Sales & Support representative for more information about the status of your order.
Whats In a Set?

Learn all about what comes in a set of plans here. If you have any questions please contact us.
